Kiertovesipumppu Avansa 15-6-130

Tekninen kuvaus

material: cast iron , top layer anticorrosive enamel
bearing material: glass ceramic
power supply : 230V/50Hz
power output based on speed (1/2/3): 46W / 67W / 93W
maximum flow rate based on speed (1/2/3): 21L/min / 35L/min / 45L/min
maximum line pressure: 10 bar
protection: IP44
discharge: 6 m
mounting length: 130 mm
pipe diameter: DN15
connection thread – nut: 1″/ 3/4″, thread: 1″
maximum displacement (m): 3/5/6
maximum temperature : 120 °C
